BS 3641-2:1980
Symbols for machine tools Specification for numerical control symbols
Formát
Dostupnost
Cena a měna
Anglicky Zabezpečené PDF
K okamžitému stažení
4800 Kč
Anglicky Tisk
Skladem
4800 Kč
| Označení normy: | BS 3641-2:1980 |
| Počet stran: | 22 |
| Vydáno: | 1980-09-30 |
| ISBN: | 0 580 11558 5 |
| Status: | Standard |
Popis
BS 3641-2:1980
This standard BS 3641-2:1980 Symbols for machine tools is classified in these ICS categories:
- 25.040.20 Numerically controlled machines
- 01.080.20 Graphical symbols for use on specific equipment
This British Standard specifies basic designs for symbols intended for use on indicator plates of numerically controlled (N.C.) machine tools.
Drawings in this standard indicate the form of symbols only, and not their absolute dimensions.
The standard gives recommendations for proportions to be used in the design of symbols, independent of actual dimensions, and provides for the grouping together of symbols selected according to individual requirements.
Examples of groupings of symbols are given in appendix A for guidance.
NOTE. An index to BS 3641 : Parts 1,2 and 3 is given in PD 6490.
Basic designs for symbols for use on indicator plates of numerically controlled machine tools.
