sklademVydáno: 2011-08-31
BS EN 60191-6-12:2011
Mechanical standardization of semiconductor devices General rules for the preparation of outline drawings of surface mounted semiconductor device packages. Design guidelines for fine-pitch land grid array (FLGA)
Formát
Dostupnost
Cena a měna
Anglicky Zabezpečené PDF
K okamžitému stažení
6820 Kč
Čtěte normu po dobu 1 hodiny. Více informací v kategorii E-READING
This standard BS EN 60191-6-12:2011 Mechanical standardization of semiconductor devices is classified in these ICS categories:
01.100.25 Electrical and electronics engineering drawings
31.080.01 Semiconductor devices in general
IEC 60191-6-12:2011 provides standard outline drawings, dimensions, and recommended variations for all fine-pitch land grid array packages (FLGA) with terminal pitch of 0,8 mm or less. This edition includes the following significant changes with respect to the previous edition: - scope is expanded so that this standard include the square type FLGA. The title of this standard has been changed accordingly: "Rectangular type" has been deleted from the title; - ball pitch of 0,3 mm has been added; - datum is changed from the body datum to the ball datum; - combination lists of D, E, MD, and ME have been revised.
