BS EN 60603-7-5:2010
Connectors for electronic equipment Detail specification for 8-way, shielded, free and fixed connectors, for data transmissions with frequencies up to 250 MHz
| Označení normy: | BS EN 60603-7-5:2010 |
| Počet stran: | 106 |
| Vydáno: | 2010-08-31 |
| ISBN: | 978 0 580 67402 0 |
| Status: | Standard |
BS EN 60603-7-5:2010
This standard BS EN 60603-7-5:2010 Connectors for electronic equipment is classified in these ICS categories:
- 31.220.10 Plug-and-socket devices. Connectors
This part of IEC 60603-7 covers IEC 60603-7-5 connectors, and specifies mechanical and environmental requirements, and electrical transmission requirements for frequencies up to 250 MHz. These connectors are typically used as category 6 connectors in class E cabling systems specified in ISO/IEC 11801:2002.
These connectors are intermateable, interoperable, and backward compatible with other IEC 60603-7 series connectors. While the definition of interoperable is being discussed within IEC, “interoperable” in this standard means the following: The fixed and the free connector are capable of interconnecting with any IEC 60603-7 series connector, and that when it is interconnected, it fully meets all requirements of the lower frequency IEC 60603-7 series standard.
NOTE Transmission performance categories: in this part of IEC 60603-7, the term “category”, when used in reference to transmission performance, refers to those categories defined by ISO/IEC 11801:2002.
