sklademVydáno: 2014-09-30
BS EN 61076-2-109:2014
Connectors for electronic equipment. Product requirements Circular connectors. Detail specification for connectors with M 12 × 1 screw-locking, for data transmission frequencies up to 500 MHz
Formát
Dostupnost
Cena a měna
Anglicky Zabezpečené PDF
K okamžitému stažení
7564 Kč
Anglicky Tisk
Skladem
7564 Kč
| Označení normy: | BS EN 61076-2-109:2014 |
| Počet stran: | 34 |
| Vydáno: | 2014-09-30 |
| ISBN: | 978 0 580 71532 7 |
| Status: | Standard |
Popis
BS EN 61076-2-109:2014
This standard BS EN 61076-2-109:2014 Connectors for electronic equipment. Product requirements is classified in these ICS categories:
- 31.220.10 Plug-and-socket devices. Connectors
This part of IEC 61076 describes circular connectors with IP 65/IP 67 degree of protection and suitable for data transmission with frequencies up to 500 MHz. Applications include, but are not limited to, vision systems and data acquisition. These connectors consist of fixed and free connectors, either rewireable or non-rewireable, with M12 x 1 screw-locking. Male connectors have round contacts ∅ 0,6 mm.
This standard covers two different types of connectors, denominated X and H, with different contact arrangement, not mutually interchangeable, but with common ratings and purposes.
