sklademVydáno: 2015-06-30
BS EN 61169-51:2015
Radio-frequency connectors Sectional specification for RF coaxial connectors with inner diameter of outer conductors 13,5 mm with bayonet lock. Characteristic impedance 50 O (type QLI)
Formát
Dostupnost
Cena a měna
Anglicky Zabezpečené PDF
K okamžitému stažení
7998 Kč
Čtěte normu po dobu 1 hodiny. Více informací v kategorii E-READING
This standard BS EN 61169-51:2015 Radio-frequency connectors is classified in these ICS categories:
33.120.30 RF connectors
IEC 61169-51:2015 provides information and rules for the preparation of detail specifications (DS) for type QLI R.F. coaxial connectors with quick lock. The connectors are normally used with 50 Ohms corrugated cable and flexible cables for middle power applications in an operating range up to 6 GHz. It describes the interface dimensions for general purpose connectors with gauging information and the mandatory tests selected from IEC 61169-1 applicable to all detail specifications relative to type QLI connectors. This specification indicates the recommended performance characteristics to be considered when writing a DS and covers all tests schedules and inspection requirements.
