BS EN IEC 60332-3-22:2018

This standard BS EN IEC 60332-3-22:2018 Tests on electric and optical fibre cables under fire conditions is classified in these ICS categories:

• 33.180.10 Fibres and cables
• 29.020 Electrical engineering in general
• 29.060.20 Cables
• 13.220.40 Ignitability and burning behaviour of materials and products
• 97.120 Automatic controls for household use

This part of IEC 60332 covers category A for methods of test for the assessment of vertical flame spread of vertically mounted bunched wires or cables, electrical or optical, under defined conditions.

This document relates to cables installed on the test ladder to achieve a nominal total volume of non-metallic material of 7 l/m of test sample. The flame application time is 40 min. The method of mounting uses the front of the ladder, a standard or wide ladder being used for cables having a conductor cross-section greater than 35 mm ² according to the number of test pieces required, and a standard ladder for conductor cross-sections 35 mm ² and smaller. The category is intended for general use where high volumes of non-metallic material are required to be evaluated.

The test is intended for type approval testing. The requirements for the selection of cables for testing are given in Annex A. The flame spread is measured as the extent of damage of the cable sample. This procedure can be used to demonstrate the cable’s ability to limit flame spread.

A recommended performance requirement is given in Annex B.
