sklademVydáno: 2025-02-04
BS EN IEC 61188-6-3:2025 Circuit boards and circuit board assemblies. Design and use Land pattern design. Description of land pattern for through hole components (THT)

BS EN IEC 61188-6-3:2025

Circuit boards and circuit board assemblies. Design and use Land pattern design. Description of land pattern for through hole components (THT)

Formát
Dostupnost
Cena a měna
Anglicky Zabezpečené PDF
K okamžitému stažení
7998 Kč
Čtěte normu po dobu 1 hodiny. Více informací v kategorii E-READING
Čtení normy
na 1 hodinu
799.80 Kč
Čtěte normu po dobu 24 hodin. Více informací v kategorii E-READING
Čtení normy
na 24 hodin
2399.40 Kč
Anglicky Tisk
Skladem
7998 Kč
Označení normy:BS EN IEC 61188-6-3:2025
Počet stran:36
Vydáno:2025-02-04
ISBN:978 0 539 16377 3
Status:Standard
Popis

BS EN IEC 61188-6-3:2025


This standard BS EN IEC 61188-6-3:2025 Circuit boards and circuit board assemblies. Design and use is classified in these ICS categories:
  • 31.190 Electronic component assemblies
  • 31.180 Printed circuits and boards
IEC 61188-6-3:2024 specifies the requirements for lands and land pattern on circuit boards for the mounting of components with leads by soldering based on the solder joint requirements of IEC 61191-1 and IEC 61191-3. This part of IEC 61188 specifies the requirements for soldering surfaces on circuit boards. This includes lands and land pattern for surface mounted components and also solderable hole configurations for through hole mounted components. These requirements are based on the solder joint requirements of IEC 61191-1, IEC 61191-2, IEC 61191-3 and IEC 61191-4. This first edition partially cancels and replaces the IEC 61188-5 series of International Standards. The significant technical changes with respect to the previous edition are listed in the Introduction and further detailed information and calculations can be found in Annex A.
