Hlavní stránka>BS EN IEC 61869-15:2019 Instrument transformers Additional requirements for voltage transformers for DC applications
Sponsored link
sklademVydáno: 2019-07-12
BS EN IEC 61869-15:2019 Instrument transformers Additional requirements for voltage transformers for DC applications

BS EN IEC 61869-15:2019

Instrument transformers Additional requirements for voltage transformers for DC applications

Formát
Dostupnost
Cena a měna
Anglicky Zabezpečené PDF
K okamžitému stažení
7998 Kč
Čtěte normu po dobu 1 hodiny. Více informací v kategorii E-READING
Čtení normy
na 1 hodinu
799.80 Kč
Čtěte normu po dobu 24 hodin. Více informací v kategorii E-READING
Čtení normy
na 24 hodin
2399.40 Kč
Anglicky Tisk
Skladem
7998 Kč
Označení normy:BS EN IEC 61869-15:2019
Počet stran:42
Vydáno:2019-07-12
ISBN:978 0 580 87998 2
Status:Standard
Popis

BS EN IEC 61869-15:2019


This standard BS EN IEC 61869-15:2019 Instrument transformers is classified in these ICS categories:
  • 17.220.20 Measurement of electrical and magnetic quantities
IEC 61869-15:2018 provides all requirements specific to voltage transformers to be used in DC applications (DCVTs), whatever the technology used. The output signal can be analogue or digital.
It is applicable to newly manufactured voltage transformers used for measuring, protection and/or control applications in DC power systems with a rated voltage above 1,5 kV.
This document covers passive voltage dividers as well as active voltage transformers, used for measurement, control and protection.
The general configuration of a single-pole low-power instrument transformer is described in Figure 601 of IEC 61869-6:2016.
IEC 61869-15:2018 applies to voltage transformers (VT) intended to be used in DC applications with the following functions:
•    measure DC voltage (with significant harmonics);
•    withstand DC voltage.
Two main technologies of DC converters exist today: LCC and VSC
•    Line-commutated converters (LCC) are based on thyristor converters. They are characterized by a single direction of current flow, and a voltage polarity reversal possibility. Significant voltage and current harmonics exist up to frequencies of about 3 kHz to 4 kHz.
•    Voltage source converters (VSC) are based on transistor converters. They are characterized by a bi-directional current flow and a single voltage polarity.  Voltage and current harmonics exist up to frequencies of about 20 kHz.
