BS ISO 13012-1:2018

This standard BS ISO 13012-1:2018 Rolling bearings. Accessories for sleeve type linear ball bearings is classified in these ICS categories:

• 21.100.20 Rolling bearings

This document specifies the boundary dimensions, other relevant dimensions and the corresponding tolerances of accessories for sleeve type linear ball bearings which are specified in ISO 10285.

This document applies to:

• the following housings:

  • closed and adjustable flangeless housings for series 1 sleeve type linear ball bearings,

  • closed and adjustable flanged housings for series 3 sleeve type linear ball bearings,

  • open flanged housings for series 3 sleeve type linear ball bearings,

  • closed and adjustable flangeless housings for series 3 sleeve type linear ball bearings,

  • open and open adjustable flangeless housings for series 3 sleeve type linear ball bearings;

• the following shaft support rails:

  • standard height shaft support rails for series 3 sleeve type linear ball bearings,

  • low height shaft support rails for series 3 sleeve type linear ball bearings;

• the following shaft support blocks:

  • flanged shaft support blocks for series 1 and 3 sleeve type linear ball bearings,

  • flangeless shaft support blocks for series 1 and 3 sleeve type linear ball bearings;

• solid and tubular shafts for series 1 and 3 sleeve type linear ball bearings.
