BS ISO 3601-4:2008 Fluid power systems. O-rings Anti-extrusion rings (back-up rings)

BS ISO 3601-4:2008

Fluid power systems. O-rings Anti-extrusion rings (back-up rings)

Formát
Dostupnost
Cena a měna
Anglicky Zabezpečené PDF
K okamžitému stažení
4650 Kč
Čtěte normu po dobu 1 hodiny. Více informací v kategorii E-READING
Čtení normy
na 1 hodinu
465.00 Kč
Čtěte normu po dobu 24 hodin. Více informací v kategorii E-READING
Čtení normy
na 24 hodin
1395.00 Kč
Anglicky Tisk
Skladem
4650 Kč
Označení normy:BS ISO 3601-4:2008
Počet stran:22
Vydáno:2008-07-31
ISBN:978 0 580 56330 0
Status:Standard
Popis

BS ISO 3601-4:2008


This standard BS ISO 3601-4:2008 Fluid power systems. O-rings is classified in these ICS categories:
  • 83.140.50 Seals
  • 23.100.60 Filters, seals and contamination of fluids

This part of ISO 3601 specifies dimensions and tolerances for five types of anti-extrusion rings, which are also known as back-up rings:

  1. spiral type (T1);

  2. angle cut type (T2);

  3. solid type (T3);

  4. angle cut concave type (T4);

  5. solid concave type (T5).

These anti-extrusion rings are for use with selected O-ring sizes as specified in ISO 3601-1 and the relevant housing dimensions specified in ISO 3601-2.
