sklademVydáno: 2021-02-03
BS ISO 4156-3:2021
Straight cylindrical involute splines. Metric module, side fit Inspection
Formát
Dostupnost
Cena a měna
Anglicky Zabezpečené PDF
K okamžitému stažení
8990 Kč
Anglicky Tisk
Skladem
8990 Kč
| Označení normy: | BS ISO 4156-3:2021 |
| Počet stran: | 56 |
| Vydáno: | 2021-02-03 |
| ISBN: | 978 0 539 03894 1 |
| Status: | Standard |
Popis
BS ISO 4156-3:2021
This standard BS ISO 4156-3:2021 Straight cylindrical involute splines. Metric module, side fit is classified in these ICS categories:
- 21.120.30 Keys and keyways, splines
This document provides data, guidance and requirements for the inspection of straight (non-helical) side fitting cylindrical involute splines.
Limiting dimensions, tolerances, manufacturing deviations and their effects on the fit between connecting coaxial spline elements are defined and tabulated. Linear dimensions are expressed in millimetres and angular dimensions in degrees.
