sklademVydáno: 1975-01-15
BS 9133 N001 to 003:1975
Detail specification for single turn low power non-wirewound rotary potentiometers. Spindle insulated from resistance element, spindle and panel sealed or container, spindle and panel sealed. Full assessment level
Format
Availability
Price and currency
Anglicky Secure PDF
Immediate download
254.31 €
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
25.43 €
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
76.29 €
Anglicky Hardcopy
In stock
254.31 €
| Označení normy: | BS 9133 N001 to 003:1975 |
| Počet stran: | 24 |
| Vydáno: | 1975-01-15 |
| ISBN: | 0 580 08108 7 |
| Status: | Standard |
DESCRIPTION
BS 9133 N001 to 003:1975
This standard BS 9133 N001 to 003:1975 Detail specification for single turn low power non-wirewound rotary potentiometers. Spindle insulated from resistance element, spindle and panel sealed or container, spindle and panel sealed. Full assessment level is classified in these ICS categories:
- 31.040.20 Potentiometers, variable resistors
Preferred resistance values 1.0, 2.2 and 4.7 in each decade; resistance laws - linear, non-linear and reverse non-linear; selection tolerances ±20%, ±10%; rated dissipation - spindle and panel sealed types 0.25 W and 1.375 W (linear law) - container, spindle and panel sealed 0.7 W (linear law) (rated dissipation halved for logarithmic and reverse logarithmic laws); temperature characteristic of resistance ±6.5%. Range of spindle and mounting details in appendices.
