BS EN 13852-3:2021

• 53.020.20 Cranes
• 47.020.40 Lifting and cargo handling equipment

This document applies to light offshore cranes including their supporting pedestals and structures.

This document is applicable to light offshore cranes, whose structures are made of steel, and fulfil all of the following characteristics:

1. maximum rated capacity 15 tonnes or maximum static load moment 3 000 kNm;

2. limitation for off-board lifting operation up to H _s = 2,0 m and wind speed 15 m/s (3 s gust);

3. maximum number of working cycles class U ₁ ( C ? 3,15 × 10 ⁴) according to EN 13001-1 .

This document provides requirements for all significant hazards, hazardous situations and events relevant to light offshore cranes for lifting of goods and lifting of persons, when used as intended and under conditions foreseen by the risk assessment (see Clause 4).

This document is applicable to light offshore cranes, which are manufactured after the date of approval by CEN of this document.

This document is not applicable for:

1. transportation, assembly, disabling, scrapping, installation or erecting of the crane;

2. any item attached to the hook, such as loads, non-fixed load lifting attachments, lifting accessories, baskets, carriers and containers;

3. lifting operations in ambient temperatures below ?20 °C;

4. lifting operations in ambient temperatures above 45 °C;

5. lifting operations involving more than one crane;

6. accidental loads as result of collisions, earthquakes, explosions, etc., which are not covered by exceptional loads defined in Table B.7;

7. emergency personnel rescue operations (except training);

8. subsea lifting operations;

9. general purpose offshore cranes (covered by EN 13852?1 ), floating cranes and motion compensated cranes.
