BS EN 50064:2018

This standard BS EN 50064:2018 High-voltage switchgear and controlgear. Gas-filled wrought aluminium and aluminium alloy enclosures is classified in these ICS categories:

• 29.130.10 High voltage switchgear and controlgear

This document applies to wrought aluminium and aluminium alloy enclosures and their welding. These enclosures are pressurized with dry air, inert gases, for example sulphur hexafluoride or nitrogen or a mixture of such gases, used in indoor and outdoor installations of high-voltage switchgear and controlgear with rated voltages above 1 kV, where the gas is used principally for its dielectric and/or arc-quenching properties with rated voltages.

• above 1 kV and up to and including 52 kV concerning gas-filled compartments with design pressure higher than 300 kPa relative pressure (gauge);

• above 52 kV concerning all gas-filled compartments. The enclosures comprise parts of electrical equipment not necessarily limited to the following examples:

• circuit-breakers;

• switch-disconnectors;

• disconnectors;

• earthing switches;

• current transformers;

• voltage transformers;

• surge arrestors;

• busbars and connections;

• etc.

The scope also covers enclosures of pressurized components such as the centre chamber of live tank switchgear, gas-insulated current transformers, etc.
