Homepage>BS EN 60191-6:2009 Mechanical standardization of semiconductor devices General rules for the preparation of outline drawings of surface mounted semiconductor device packages
Sponsored link
sklademVydáno: 2010-04-30
BS EN 60191-6:2009 Mechanical standardization of semiconductor devices General rules for the preparation of outline drawings of surface mounted semiconductor device packages

BS EN 60191-6:2009

Mechanical standardization of semiconductor devices General rules for the preparation of outline drawings of surface mounted semiconductor device packages

Format
Availability
Price and currency
Anglicky Secure PDF
Immediate download
298.32 €
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
29.83 €
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
89.50 €
Anglicky Hardcopy
In stock
298.32 €
Označení normy:BS EN 60191-6:2009
Počet stran:42
Vydáno:2010-04-30
ISBN:978 0 580 59338 3
Status:Standard
DESCRIPTION

BS EN 60191-6:2009


This standard BS EN 60191-6:2009 Mechanical standardization of semiconductor devices is classified in these ICS categories:
  • 31.080.01 Semiconductor devices in general
IEC 60191-6:2009 gives general rules for the preparation of outline drawings of surface-mounted semiconductor devices. It supplements IEC 60191-1 and IEC 60191-3. It covers all surface-mounted devices discrete semiconductors with lead count of greater or equal to 8, as well as integrated circuits classified as form E in Clause 3 of IEC 60191-4. This third edition of IEC 60191-6 cancels and replaces the second edition, published in 2004 and constitutes a technical revision. This edition includes the following significant changes with respect to the previous edition:
a) scope is modified to cover all surface-mounted devices discrete semiconductors with lead count of greater or equal to 8;
b) editorial modifications on several pages; and
c) technical revision to ball grid array package (BGA) especially its geometrical drawing format. (two types of BGA would unify as one type as a result of revising drawing format.
