BS EN 60335-2-103:2015
Household and similar electrical appliances. Safety Particular requirements for drives for gates, doors and windows
| Označení normy: | BS EN 60335-2-103:2015 |
| Počet stran: | 42 |
| Vydáno: | 2015-05-31 |
| ISBN: | 978 0 580 90151 5 |
| Status: | Standard |
BS EN 60335-2-103:2015
This standard BS EN 60335-2-103:2015 Household and similar electrical appliances. Safety is classified in these ICS categories:
- 91.060.50 Doors and windows
- 13.120 Domestic safety
This clause of Part 1 is replaced by the following.
This European Standard deals with the safety of electric drives for horizontally and vertically moving gates, doors, garage doors and windows for household and similar purposes, their rated voltage being not more than 250 V for single-phase drives and 480 V for other drives. It also covers the hazards associated with the movement of the gates, doors, garage doors and windows.
Battery-operated appliances and other d.c. supplied appliances are within the scope of this standard.
Examples of places where gates, doors, garage doors and windows for household environment may also be used by non-expert users:
-
shops, offices and other working environments
-
farm houses;
-
hotels, motels and other residential type environments where they are used by clients;
-
bed and breakfast type environments.
Household environment includes the dwelling and its associated buildings, the garden, etc.
Drives being part of power operated doors, gates, windows and garage doors which are intended to be used by trained users in shops, in light industry and on farms, are also within the scope of this standard.
Examples of drives within the scope of this standard are drives for
-
folding doors;
-
revolving doors;
-
rolling doors;
-
roof windows;
-
sectional overhead doors;
-
swinging and sliding gates or doors.
Examples are shown in Figure 101.
Drives may be supplied with a driven part.
Within the standard the terms drive and appliance are interchangeable.
This standard deals with the reasonably foreseeable hazards presented by drives that are encountered by all persons in and around the installation place. However, in general, it does not take into account
-
children playing with the appliance;
-
the use of the appliance by very young children;
-
the use of the appliance by young children without supervision.
It is recognized that very vulnerable people may have needs beyond the level addressed in this standard.
Attention is drawn to the fact that in many countries additional requirements are specified by the national authorities responsible for the protection of labour and similar authorities.
Attention is drawn to the fact that for drives for powered pedestrians doors used in emergency routes and exits additional requirements as given in EN 16005 are applicable.
This standard does not apply to drives
-
for vertically moving garage doors for residential use ( EN 60335‑2‑95 );
-
for rolling shutters, awnings, blinds and similar equipment ( EN 60335‑2‑97 );
-
for specific purposes, such as fire barrier doors;
-
for doors on vehicles;
-
for doors on lifts;
-
for natural smoke exhaust ventilator not used as windows ( EN 12101‑2 )
This standard does not apply to movement of a pedestrian door where such movement is based solely on stored mechanical energy.
This European Standard does not deal with any specific requirements on noise emitted from these drives as the generated noise is not considered to be a relevant hazard. Thus the emission sound pressure level L pA is considered to be L pA ≤70 dB(A).
