BS EN 60512-27-100:2012

Connectors for electronic equipment. Tests and measurements Signal integrity tests up to 500 MHz on IEC 60603-7 series connectors. Tests 27a to 27g

Anglicky Secure PDF

Immediate download

354.57 €

You can read the standard for 1 hour. More information in the category: E-reading

Reading the standard

for 1 hour

35.46 €

You can read the standard for 24 hours. More information in the category: E-reading

Reading the standard

for 24 hours

106.37 €

Anglicky Hardcopy

In stock

354.57 €

Označení normy:	BS EN 60512-27-100:2012
Počet stran:	70
Vydáno:	2012-03-31
ISBN:	978 0 580 57942 4
Status:	Standard

DESCRIPTION

BS EN 60512-27-100:2012

This standard BS EN 60512-27-100:2012 Connectors for electronic equipment. Tests and measurements is classified in these ICS categories:

31.220.10 Plug-and-socket devices. Connectors

IEC 60512-27-100:2011 specifies the test methods for transmission performance for IEC 60603-7 series connectors up to 500 MHz. It is also suitable for testing lower frequency connectors if they meet the requirements of the detail specifications and of this standard. The test methods provided are:
- insertion loss,
- return loss,
- near-end crosstalk (NEXT),
- far-end crosstalk (FEXT),
- transverse conversion loss (TCL) and
- transverse conversion transfer loss (TCTL). For the transfer impedance (Zt) test, see IEC 60512-26-100 and for the coupling attenuation, see IEC 62153-4-12.
