Homepage>BS EN 61076-2-113:2017 Connectors for electronic equipment. Product requirements Circular connectors. Detail specification for connectors with M12 screw locking with power and signal contacts for data transmission with frequency up to 100 MHz

sklademVydáno: 2017-11-20

BS EN 61076-2-113:2017

Connectors for electronic equipment. Product requirements Circular connectors. Detail specification for connectors with M12 screw locking with power and signal contacts for data transmission with frequency up to 100 MHz

Anglicky Secure PDF

Immediate download

291.92 €

You can read the standard for 1 hour. More information in the category: E-reading

Reading the standard

for 1 hour

29.19 €

You can read the standard for 24 hours. More information in the category: E-reading

Reading the standard

for 24 hours

87.58 €

Anglicky Hardcopy

In stock

291.92 €

Označení normy:	BS EN 61076-2-113:2017
Počet stran:	42
Vydáno:	2017-11-20
ISBN:	978 0 580 85901 4
Status:	Standard

DESCRIPTION

BS EN 61076-2-113:2017

This standard BS EN 61076-2-113:2017 Connectors for electronic equipment. Product requirements is classified in these ICS categories:

31.220.10 Plug-and-socket devices. Connectors

IEC 61076-2-113:2017 describes M12 circular connectors with two data pairs and power contacts with current ratings up to 12 A, that are typically used for data and power applications in industrial premises. These connectors consist of both fixed and free connectors either rewireable or non rewireable, with screw-locking. Male connectors have round contacts diameters of 1,50 mm, 1,00 mm and 0,60 mm.
The different codings provided by this document prevent the mating of accordingly coded male or female connectors to any other similarly sized interfaces covered by other standards and the cross-mating between the different codings provided by this document.
M12 is the dimension of the thread of the screw locking mechanism of these circular connectors.
