BS EN 61169-52:2015 Radio-frequency connectors Sectional specification for series MMCX RF coaxial connectors

BS EN 61169-52:2015

Radio-frequency connectors Sectional specification for series MMCX RF coaxial connectors

Format
Availability
Price and currency
Anglicky Secure PDF
Immediate download
271.50 €
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
27.15 €
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
81.45 €
Anglicky Hardcopy
In stock
271.50 €
Označení normy:BS EN 61169-52:2015
Počet stran:32
Vydáno:2015-10-31
ISBN:978 0 580 85603 7
Status:Standard
DESCRIPTION

BS EN 61169-52:2015


This standard BS EN 61169-52:2015 Radio-frequency connectors is classified in these ICS categories:
  • 33.120.30 RF connectors

This part of IEC 61169, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for RF coaxial connectors with snap-on coupling, typically for use in 50 Ω cable networks (MMCX).

It prescribes mating face dimensions for general purpose connectors – grade 2, dimensional details of standard test connectors-grade 0, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series MMCX RF connectors.

This specification indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.

The MMCX miniature snap-on coupling structure series R.F. coaxial connector with the characteristic of normative impedance 50 Ω are used with various kinds of R.F cables and strips. The operating frequency limit is up to 6 GHz.

NOTE Metric dimension are original dimensions. All undimensioned pictorial configurations are for reference purpose only.
