Homepage>BS EN IEC 62680-1-3:2022 Universal serial bus interfaces for data and power Common components. USB Type-C® cable and connector specification

BS EN IEC 62680-1-3:2022

Universal serial bus interfaces for data and power Common components. USB Type-C® cable and connector specification

Anglicky Secure PDF

Immediate download

384.29 €

You can read the standard for 1 hour. More information in the category: E-reading

Reading the standard

for 1 hour

38.43 €

You can read the standard for 24 hours. More information in the category: E-reading

Reading the standard

for 24 hours

115.29 €

Anglicky Hardcopy

In stock

384.29 €

Označení normy:	BS EN IEC 62680-1-3:2022
Počet stran:	388
Vydáno:	2022-10-21
ISBN:	978 0 539 20419 3
Status:	Standard

DESCRIPTION

BS EN IEC 62680-1-3:2022

This standard BS EN IEC 62680-1-3:2022 Universal serial bus interfaces for data and power is classified in these ICS categories:

33.120.20 Wires and symmetrical cables
33.120.30 RF connectors
35.200 Interface and interconnection equipment

IEC 62680-1-3:2022 defines the USB Type-C® receptacles, plug and cables. The USB Type-C Cable and Connector Specification is guided by the following principles: - Enable new and exciting host and device form-factors where size, industrial design and style are important parameters - Work seamlessly with existing USB host and device silicon solutions - Enhance ease of use for connecting USB devices with a focus on minimizing user confusion for plug and cable orientation The USB Type-C Cable and Connector Specification defines a new receptacle, plug, cable and detection mechanisms that are compatible with existing USB interface electrical and functional specifications. This specification covers the following aspects that are needed to produce and use this new USB cable/connector solution in newer platforms and devices, and that interoperate with existing platforms and devices: - USB Type-C receptacles, including electro-mechanical definition and performance requirements - USB Type-C plugs and cable assemblies, including electro-mechanical definition and performance requirements - USB Type-C to legacy cable assemblies and adapters - USB Type-C-based device detection and interface configuration, including support for legacy connections - USB Power Delivery optimized for the USB Type-C connector The USB Type-C Cable and Connector Specification defines a standardized mechanism that supports Alternate Modes, such as repurposing the connector for docking-specific applications. IEC 62680-1-3:2022 cancels and replaces the fourth edition published in 2021 and constitutes a technical revision. This standard is the USB-IF publication Universal Serial Bus Type-C Cable and Connector Specification Revision 2.0. New release primarily for enabling Extended Power Range (EPR) and defining EPR cables aligning with USB Power Delivery Specification R3.1 V1.0. Also includes incorporation of all approved ECNs as the revision date plus editorial clean-up.
