BS EN IEC 63261:2024

Representation of electrical and instrument objects in digital 3D plant models during engineering

Anglicky Secure PDF

Immediate download

195.33 €

You can read the standard for 1 hour. More information in the category: E-reading

Reading the standard

for 1 hour

19.53 €

You can read the standard for 24 hours. More information in the category: E-reading

Reading the standard

for 24 hours

58.60 €

Anglicky Hardcopy

In stock

195.33 €

Označení normy:	BS EN IEC 63261:2024
Počet stran:	16
Vydáno:	2025-01-10
ISBN:	978 0 539 05998 4
Status:	Standard

DESCRIPTION

BS EN IEC 63261:2024

This standard BS EN IEC 63261:2024 Representation of electrical and instrument objects in digital 3D plant models during engineering is classified in these ICS categories:

29.020 Electrical engineering in general
25.040.40 Industrial process measurement and control

IEC 63261:2024 provides requirements for the E&I objects of a digital 3D plant model, used in the engineering phase to design and construct a process plant and its instrumentation. It provides guidance how to model plants and their electrical and instrumentation equipment. This document also specifies the content and the possible output of the 3D plant model at project milestones. This document can be used by the contractual partners to agree upon the content of the 3D plant model to be delivered at specified milestones. This document does not specify the transfer and format of digital 3D plant models. This document does not specify definitions or instructions to equipment representations and details of elements in the 3D plant model not belonging to electrical and instrumentation domains.
