BS EN ISO 8560:2019
Technical drawings. Construction drawings. Representation of modular sizes, lines and grids
Format
Availability
Price and currency
Anglicky Secure PDF
Immediate download
165.40 €
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
16.54 €
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
49.62 €
Anglicky Hardcopy
In stock
165.40 €
| Označení normy: | BS EN ISO 8560:2019 |
| Počet stran: | 14 |
| Vydáno: | 2019-05-08 |
| ISBN: | 978 0 580 96756 6 |
| Status: | Standard |
DESCRIPTION
BS EN ISO 8560:2019
This standard BS EN ISO 8560:2019 Technical drawings. Construction drawings. Representation of modular sizes, lines and grids is classified in these ICS categories:
- 01.100.30 Construction drawings
- 91.010.30 Technical aspects
This document lays down rules for the representation of modular sizes, lines and grids on construction drawings. The basic module M is 100 mm (see ISO 1006).
Generally, modular sizes are for use on design drawings, but can also be added to production drawings for manufacturing, orientation and location.
