sklademVydáno: 2017-10-13
BS ISO 12251:2017
Diesel engines. Clamp mounted CR fuel injectors. Mounting dimensions
Format
Availability
Price and currency
Anglicky Secure PDF
Immediate download
194.98 €
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
19.50 €
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
58.49 €
Anglicky Hardcopy
In stock
194.98 €
| Označení normy: | BS ISO 12251:2017 |
| Počet stran: | 18 |
| Vydáno: | 2017-10-13 |
| ISBN: | 978 0 580 92509 2 |
| Status: | Standard |
DESCRIPTION
BS ISO 12251:2017
This standard BS ISO 12251:2017 Diesel engines. Clamp mounted CR fuel injectors. Mounting dimensions is classified in these ICS categories:
- 43.060.40 Fuel systems
This document specifies dimensional requirements for clamp mounted CR fuel injectors and their corresponding cylinder head features in diesel engines.
According to the injector nozzle capnut, the clamp mounted CR fuel injectors can be divided into two types:
Type A, where the nozzle capnut is straight (see Figure 4);
Type B, where the nozzle capnut is stepped (see Figure 5).
Each clamp mounted CR fuel injector type is subdivided by a series of different sizes.
NOTE This differentiation corresponds to the relationship between the two guide diameters of the clamp mounted CR fuel injectors.
