BS ISO 1641-3:2011
End mills and slot drills Dimensions and designation of milling cutters with 7/24 taper shanks
| Označení normy: | BS ISO 1641-3:2011 |
| Počet stran: | 16 |
| Vydáno: | 2011-07-31 |
| ISBN: | 978 0 580 67716 8 |
| Status: | Standard |
BS ISO 1641-3:2011
This standard BS ISO 1641-3:2011 End mills and slot drills is classified in these ICS categories:
- 25.100.20 Milling tools
This part of ISO 1641 specifies the general dimensions and designation of the following milling cutters with 7/24 taper shanks:
-
end mills, flat-ended or ball-nosed — normal series and long series (manual changers);
-
slot drills — short series and normal series (manual changers);
-
end mills, flat-ended — normal series and long series (automatic changers).
Tool shanks with 7/24 taper for manual tool changers are in accordance with ISO 297. Tool shanks with 7/24 taper for automatic tool changers are in accordance with ISO 7388-1 and ISO 7388-2.
It is not applicable to end mills and slot drills with cylindrical shank, which are dealt with in ISO 1641-1; it is not applicable to those with Morse taper shank, which are dealt with in ISO 1641-2.
This part of ISO 1641 is not applicable to solid hardmetal end mills and slot drills.
