BS ISO 26623-1:2020

Polygonal taper interface with flange contact surface Dimensions and designation of shanks

Anglicky Secure PDF

Immediate download

195.02 €

You can read the standard for 1 hour. More information in the category: E-reading

Reading the standard

for 1 hour

19.50 €

You can read the standard for 24 hours. More information in the category: E-reading

Reading the standard

for 24 hours

58.51 €

Anglicky Hardcopy

In stock

195.02 €

Označení normy:	BS ISO 26623-1:2020
Počet stran:	22
Vydáno:	2020-12-02
ISBN:	978 0 539 02462 3
Status:	Standard

DESCRIPTION

BS ISO 26623-1:2020

This standard BS ISO 26623-1:2020 Polygonal taper interface with flange contact surface is classified in these ICS categories:

25.060.20 Dividing and tool-workpiece holding devices

This document specifies dimensions for polygonal taper interfaces with flange contact surface — polygon shanks for automatic and manual tool exchange to be applied on machine tools (e. g. turning machines, drilling machines, milling machines and turn/milling centres as well as grinding machines). A range of shank sizes is specified.

These shanks incorporate a grooved flange to enable automatic tool exchange. The clamping can be realized by a circular groove using clamping segments or internal screw threads using centre-bolts.

The torque is transmitted by form lock (polygon).
