sklademVydáno: 2001-08-15
BS ISO 3019-1:2001
Hydraulic fluid power. Dimensions and identification code for mounting flanges and shaft ends of displacement pumps and motors Inch series shown in metric units
Format
Availability
Price and currency
Anglicky Secure PDF
Immediate download
183.40 €
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
18.34 €
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
55.02 €
Anglicky Hardcopy
In stock
183.40 €
| Označení normy: | BS ISO 3019-1:2001 |
| Počet stran: | 20 |
| Vydáno: | 2001-08-15 |
| ISBN: | 0 580 38020 3 |
| Status: | Standard |
DESCRIPTION
BS ISO 3019-1:2001
This standard BS ISO 3019-1:2001 Hydraulic fluid power. Dimensions and identification code for mounting flanges and shaft ends of displacement pumps and motors is classified in these ICS categories:
- 23.100.10 Pumps and motors
- 23.100.99 Other fluid power system components
This part of ISO 3019 specifies sizes and dimensions and establishes an identification code for the two- and four-bolt mounting flanges and the shaft ends of positive-displacement, rotary hydraulic fluid power pumps and motors. It is applicable to cylindrical keyed shaft ends with an external thread, as well as to those without a thread, to conical keyed shaft ends with an external thread and to 30° involute spline shaft ends.
NOTE Involute spline is in accordance with SAE J744[1].
