sklademVydáno: 2018-09-27
BS ISO 8140:2018
Pneumatic fluid power. Cylinders, 1 000 kPa (10 bar) series. Mounting dimensions of rod-end clevises
Format
Availability
Price and currency
Anglicky Secure PDF
Immediate download
154.05 €
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
15.41 €
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
46.22 €
Anglicky Hardcopy
In stock
154.05 €
| Označení normy: | BS ISO 8140:2018 |
| Počet stran: | 14 |
| Vydáno: | 2018-09-27 |
| ISBN: | 978 0 580 98351 1 |
| Status: | Standard |
DESCRIPTION
BS ISO 8140:2018
This standard BS ISO 8140:2018 Pneumatic fluid power. Cylinders, 1 000 kPa (10 bar) series. Mounting dimensions of rod-end clevises is classified in these ICS categories:
- 23.100.20 Cylinders
This document specifies the mounting dimensions required for interchangeability of rod-end clevises of pneumatic cylinders. The rod-end clevises have been designed specifically for use with 1 000 kPa [10 bar1] series cylinders manufactured in accordance with ISO 6432 and ISO 15552, but this does not limit their application.
The clevises are used on piston rods of pneumatic cylinders for mechanically transmitting the cylinder force. The design of the clevises is based on the maximum forces resulting from the specified internal diameter of the cylinders and pressure according to ISO 6432, ISO 15552 and ISO 21287.
1 1 bar = 100 kPa = 105 Pa; 1 Pa = 1 N/m2.
