IEC 60297-3-108:2014
Mechanical structures for electronic equipment - Dimensions of mechanical structures of the 482,6 mm (19 in) series - Part 3-108: Dimensions of R-type subracks and plug-in units
Structures mécaniques pour équipements électroniques - Dimensions des structures mécaniques de la série 482,6 mm (19 pouces) - Partie 3-108: Dimensions des bacs de type R et des blocs enfichables
Format
Availability
Price and currency
Anglicky/Francouzsky Hardcopy
skladem
214.83 €
Anglicky/Francouzsky PDF
Immediate download
214.83 €
| Označení normy: | IEC 60297-3-108:2014 |
| Vydáno: | 2014-09-09 |
| Jazyk: | Anglicky/Francouzsky |
DESCRIPTION
IEC 60297-3-108:2014
IEC 60297-3-108:2014 provides dimensions and features for R-type subracks and plug-in units, i.e. ruggedized variants of the mechanical structures of the 482,6 mm (19 in) series, with enhanced vibration and shock resistance and/or improved EMC performance, for use in more harsh environment. This leads to a subrack standard which is externally compatible with IEC 60297-3-100 but internally largely incompatible with IEC 60297-3-101. R-type subracks, chassis integrated subracks and plug-in units incorporate dimensions and features which provide for a higher level of ruggedness, compared with IEC 60297-3-101 (test set-up and load definitions are selected from IEC 61587-1 and IEC 61587-5). Key words: R-Type, Subracks, Plug-in unit
