Homepage>IEC 60603-4:1987 - Connectors for frequencies below 3 MHz for use with printed boards - Part 4: Two-part connectors for printed boards having contacts spaced at 1,91 mm (0,075 in) centres and staggered terminations at that same spacing
sklademVydáno: 1987-03-15
IEC 60603-4:1987 - Connectors for frequencies below 3 MHz for use with printed boards - Part 4: Two-part connectors for printed boards having contacts spaced at 1,91 mm (0,075 in) centres and staggered terminations at that same spacing

IEC 60603-4:1987

Connectors for frequencies below 3 MHz for use with printed boards - Part 4: Two-part connectors for printed boards having contacts spaced at 1,91 mm (0,075 in) centres and staggered terminations at that same spacing

Connecteurs pour fréquences inférieures à 3 MHz pour utilisation avec cartes imprimées - Partie 4: Connecteurs enfichables à deux rangées pour cartes imprimées dont les contacts sont au pas de 1,91 mm (0,075 in) et les sorties décalées du même pas

Format
Availability
Price and currency
Hardcopy
skladem
129.28 €
PDF
Immediate download
129.28 €
Označení normy:IEC 60603-4:1987
Vydáno:1987-03-15
DESCRIPTION

IEC 60603-4:1987

Applies to a group of related rectangular, multicontact, two-part printed board connectors with male and female contacts in conjunction with either solder or solderless terminations (such as wrap type). All connectors have the same contact spacing using the basic grid of 1.91 mm (0.075 in). The attachment of the connector to the printed board is accomplished with a series of cantilever solder tabs, which are distributed evenly on both sides of the board.
