sklademVydáno: 2023-01-31
IEC 61076-3-126:2023
Connectors for electrical and electronic equipment - Product requirements - Part 3-126: Rectangular connectors - Detail specification for 5-way power connectors for industrial environments with push-pull locking
Connecteurs pour équipements électriques et électroniques - Exigences de produit - Partie 3-126: Connecteurs rectangulaires - Spécification particulière pour les connecteurs de puissance 5 voies destinés aux environnements industriels avec verrouillage de type pousser-tirer
Format
Availability
Price and currency
Anglicky/Francouzsky Hardcopy
skladem
305.64 €
Anglicky/Francouzsky PDF
Immediate download
305.64 €
| Označení normy: | IEC 61076-3-126:2023 |
| Vydáno: | 2023-01-31 |
| Jazyk: | Anglicky/Francouzsky |
DESCRIPTION
IEC 61076-3-126:2023
IEC 61076-3-126:2023 covers 5-pole rectangular connectors for electric power supply up to 16 A per pole. These connectors consist of fixed and free connectors, both either rewirable or non-rewirable. This document employs the general function principles of the push-pull connector housing system described in IEC 61076‑3‑117 with IP65/IP67 degree of protection according to IEC 60529 for harsh applications. Male connectors have pin contacts with square cross-section with 1 mm side. Connectors according to this document are without breaking capacity COC according to IEC 61984, therefore they are not intended to be engaged or disengaged in normal use when live or under load.
