IEC 61076-8-109:2023
Connectors for electrical and electronic equipment - Product requirements - Part 8-109: Power connectors - Detail specification for 2P 130 A, 1 000 V plus 2P 5 A 50 V rectangular housing shielded connectors with IP65/IP68 degree of protection when mated and locked, and IPXXB when unmated
Connecteurs pour équipements électriques et électroniques - Exigences de produit - Partie 8-109: Connecteurs d’alimentation - Spécification particulière pour les connecteurs blindés rectangulaires à 2 pôles de 130 A et 1 000 V plus 2 pôles de 5 A et 50 V, avec un degré de protection IP65/IP68 lorsqu’ils sont accouplés et verrouillés, et IPXXB lorsqu’ils sont désaccouplés, logés dans un boîtier
Format
Availability
Price and currency
Anglicky/Francouzsky Hardcopy
skladem
267.08 €
Anglicky/Francouzsky PDF
Immediate download
267.08 €
| Označení normy: | IEC 61076-8-109:2023 |
| Vydáno: | 2023-05-12 |
| Jazyk: | Anglicky/Francouzsky |
DESCRIPTION
IEC 61076-8-109:2023
IEC 61076-8-109:2023 describes free and fixed rectangular connectors with: - 2P power plus 2P signal contacts; - plastic housing with locking lever and four possible codings; - 130 A rated current, 1 000 V DC rated voltage on the power section; - 5 A rated current, 50 V DC rated voltage on the signal section; - individual shielding around each power contact with relevant shielding termination; - IP65/IP68 degree of protection when mated and locked and IPXXB on both plug, and receptacle parts when unmated; - hereinafter referred to as a connector, for use in electrical and electronic equipment, including overall dimensions, interface dimensions, technical characteristics, performance requirements and test methods.
