IEC 61131-10:2019

IEC 61131-10:2019 specifies an XML-based exchange format for the export and import of IEC 61131-3 projects. A complete IEC 61131-3 project implemented in an IEC 61131-3 environment can be transferred between different programming environments. It allows for the exchange of configuration elements, data types, and POUs written in: • the textual language, instruction list (IL), • the textual language, structured text (ST), • the graphical language, ladder diagram (LD), • the graphical language, function block diagram (FBD), and • sequential function chart (SFC). The exchange format is specified as a corresponding XML schema. The XML schema is an independent file with the .xsd extension and as such part of this specification. The specification of this schema is contained in Annex A. Annex B provides recommended schemata for extensions. An example XML document is given in Annex C. It is assumed that the reader of this document is familiar with XML technology.
