IEC 61169-24:2019
Radio-frequency connectors - Part 24: Sectional specification - Radio frequency coaxial connectors with screw coupling, typically for use in 75 Ω cable networks (type F)
Connecteurs pour fréquences radioeléctriques - Partie 24: Spécification intermédiaire - Connecteurs coaxiaux pour fréquences radioélectriques avec couplage à vis, typiquement utilisés dans des réseaux de distribution par câbles de 75 Ω (type F)
| Označení normy: | IEC 61169-24:2019 |
| Vydáno: | 2019-07-19 |
| Jazyk: | Anglicky/Francouzsky |
IEC 61169-24:2019
IEC 61169-24:2019, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for RF coaxial connectors with screw coupling, typically for use in 75 W cable networks (type F). It describes the interface dimensions with gauging information and the mandatory tests selected from IEC 61169-1, applicable to all DS relating to type F connectors. This specification indicates the recommended performance characteristics to be considered when writing a DS and covers test schedules and inspection requirements. This third edition cancels and replaces the second edition published in 2009. This edition includes the following significant technical changes with respect to the previous edition: all drawings have been reworked and improved to allow frequency extension up to 3 GHz.
