IEC 61300-3-27:1997
Fibre optic interconnecting devices and passive components - Basic test and measurement procedures - Part 3-27: Examinations and measurements - Measurement method for the hole location of a multiway connector plug
Dispositifs d'interconnexion et composants passifs à fibres optiques - Méthodes fondamentales d'essai et de mesures - Partie 3-27: Examens et mesures - Méthode de mesure pour la localisation du trou sur une fiche de connecteur multivoies
Format
Availability
Price and currency
Anglicky/Francouzsky Hardcopy
skladem
22.48 €
Anglicky/Francouzsky PDF
Immediate download
22.48 €
| Označení normy: | IEC 61300-3-27:1997 |
| Vydáno: | 1997-05-23 |
| Jazyk: | Anglicky/Francouzsky |
DESCRIPTION
IEC 61300-3-27:1997
IEC 61300-3-27:1997 is to measure the hole location of a multiway connector plug which has multiple fibre holes for arraying fibres and two guide holes for positioning two alignment pins. The following dimensions on the endface of the plug shall be accurately measured to satisfy the specified mechanical and optical performance of the connector: – distance between two guide-hole centres L; – position deviation of each fibre-hole centre Pi.
