sklademVydáno: 2022-09-15
IEC 63171-5:2022
Connectors for electrical and electronic equipment - Part 5: Detail specification for 2-way M8 and M12 circular connectors, shielded or unshielded, free and fixed - Mechanical mating information, pin assignment and additional requirements for Type 5
Connecteurs pour équipements électriques et électroniques - Partie 5: Spécification particulière pour les connecteurs circulaires M8 et M12 à 2 pôles, à fiches et embases écrantées ou non écrantées: informations d’accouplement mécanique, affectation des broches et exigences supplémentaires pour le type 5
Format
Availability
Price and currency
Anglicky/Francouzsky Hardcopy
skladem
265.08 €
Anglicky/Francouzsky PDF
Immediate download
265.08 €
| Označení normy: | IEC 63171-5:2022 |
| Vydáno: | 2022-09-15 |
| Jazyk: | Anglicky/Francouzsky |
DESCRIPTION
IEC 63171-5:2022
IEC 63171-5:2022 refers to International Standards for test and measurement, environmental testing as well as solderless connections. This part of IEC 63171 describes 2-way shielded or unshielded circular connectors with IP65/IP67 M8 or M12 locking, typically used for balanced single-pair data transmission with frequencies up to 600 MHz and with current-carrying capacity up to 4 A, for use in areas with harsh environmental conditions. These connectors consist of fixed and free connectors, either rewirable or non-rewirable. Male connectors have square cross-section contacts.
