Homepage>IEC 81714-3:2004 - Design of graphical symbols for use in the technical documentation of products - Part 3: Classification of connect nodes, networks and their encoding
sklademVydáno: 2004-10-26
IEC 81714-3:2004 - Design of graphical symbols for use in the technical documentation of products - Part 3: Classification of connect nodes, networks and their encoding

IEC 81714-3:2004

Design of graphical symbols for use in the technical documentation of products - Part 3: Classification of connect nodes, networks and their encoding

Création de symboles graphiques utilisables dans la documentation technique de produits - Partie 3: Classification des noeuds de connexion, des réseaux et leur codage

Format
Availability
Price and currency
Anglicky/Francouzsky Hardcopy
skladem
45.08 €
Anglicky/Francouzsky PDF
Immediate download
45.08 €
Označení normy:IEC 81714-3:2004
Vydáno:2004-10-26
Jazyk:Anglicky/Francouzsky
DESCRIPTION

IEC 81714-3:2004

IEC 81714-3:2004 Specifies requirements concerning the classification of connect nodes assigned to graphical symbols, being a representation of functional and product concepts. Due to the strong interrelation between the product and its corresponding graphical representation, identical classification principles are applied for both the classification of connect nodes of products as well as for the classification of networks and their representation by graphical symbols in computer-aided systems. It has the status of a horizontal standard in accordance with IEC Guide 108.
