PD CEN/CLC/TR 17603-31-09:2021

This standard PD CEN/CLC/TR 17603-31-09:2021 Space Engineering. Thermal design handbook is classified in these ICS categories:

• 49.140 Space systems and operations

In this Part 9 of the spacecraft thermal control and design data handbooks, view factors of diffuse and specular thermal surfaces are discussed.

For diffuse surfaces, calculations are given for radiation emission and absorption between different configurations of planar, cylindrical, conical, spherical and ellipsoidal surfaces for finite and infinite surfaces.

For specular surfaces the affect of reflectance on calculations for view factors is included in the calculations. View factors for specular and diffuse surfaces are also included.

The Thermal design handbook is published in 16 Parts

TR 17603‑31‑01	Thermal design handbook – Part 1: View factors
TR 17603‑31‑02	Thermal design handbook – Part 2: Holes, Grooves and Cavities
TR 17603‑31‑03	Thermal design handbook – Part 3: Spacecraft Surface Temperature
TR 17603‑31‑04	Thermal design handbook – Part 4: Conductive Heat Transfer
TR 17603‑31‑05	Thermal design handbook – Part 5: Structural Materials: Metallic and Composite
TR 17603‑31‑06	Thermal design handbook – Part 6: Thermal Control Surfaces
TR 17603‑31‑07	Thermal design handbook – Part 7: Insulations
TR 17603‑31‑08	Thermal design handbook – Part 8: Heat Pipes
TR 17603‑31‑09	Thermal design handbook – Part 9: Radiators
TR 17603‑31‑10	Thermal design handbook – Part 10: Phase – Change Capacitors
TR 17603‑31‑11	Thermal design handbook – Part 11: Electrical Heating
TR 17603‑31‑12	Thermal design handbook – Part 12: Louvers
TR 17603‑31‑13	Thermal design handbook – Part 13: Fluid Loops
TR 17603‑31‑14	Thermal design handbook – Part 14: Cryogenic Cooling
TR 17603‑31‑15	Thermal design handbook – Part 15: Existing Satellites
TR 17603‑31‑16	Thermal design handbook – Part 16: Thermal Protection System
