PD IEC TR 63262:2019

This standard PD IEC TR 63262:2019 Performance of unified power flow controller (UPFC) in electric power systems is classified in these ICS categories:

• 29.200 Rectifiers. Converters. Stabilized power supply
• 29.240.99 Other equipment related to power transmission and distribution networks

This document provides guidelines for applying unified power flow controllers (UPFC) in power systems. It includes letter symbols, terms and definitions, principles and configurations, design rules, performance requirements for key equipment, control and protection, insulation co-ordination, system performance and tests. This technical report applies to the UPFC based on modular multi-level converter (MMC) technology, as well as UPFC based on three-level converter technology.
