Hlavní stránka>IEC 60317-62:2020 - Specifications for particular types of winding wires - Part 62: Polyester glass-fibre wound, silicone resin or varnish impregnated, bare or enamelled rectangular copper wire, temperature index 200
sklademVydáno: 2020-06-10
IEC 60317-62:2020 - Specifications for particular types of winding wires - Part 62: Polyester glass-fibre wound, silicone resin or varnish impregnated, bare or enamelled rectangular copper wire, temperature index 200

IEC 60317-62:2020

Specifications for particular types of winding wires - Part 62: Polyester glass-fibre wound, silicone resin or varnish impregnated, bare or enamelled rectangular copper wire, temperature index 200

Spécifications pour types particuliers de fils de bobinage - Partie 62: Fil de section rectangulaire en cuivre nu ou émaillé, guipé de fibres de verre polyester imprégnées de résine silicone ou de vernis, d'indice de température 200

Formát
Dostupnost
Cena a měna
Anglicky/Francouzsky Tisk
skladem
1144 Kč
Anglicky/Francouzsky PDF
K okamžitému stažení
1144 Kč
Označení normy:IEC 60317-62:2020
Vydáno:2020-06-10
Jazyk:Anglicky/Francouzsky
Popis

IEC 60317-62:2020

IEC 60317-62:2020 is available as IEC 60317-62:2020 RLV which contains the International Standard and its Redline version, showing all changes of the technical content compared to the previous edition. IEC 60317-62:2020 specifies the requirements of polyester glass-fibre wound, silicone resin or varnish impregnated bare, grade 1 or grade 2 enamelled rectangular copper winding wires, temperature index 200. The impregnating agent is a silicone containing resin or varnish.The range of nominal conductor dimensions covered by this document is: - width: min. 2,0 mm max. 16,0 mm; - thickness: min. 0,80 mm max. 5,60 mm. NOTE For this type of wire, the heat shock test is inappropriate and therefore a heat shock temperature cannot be established. Consequently, a class based on the requirements for temperature index and heat shock temperature cannot be specified. This second edition cancels and replaces the first edition published in 2012. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: - revision to the title of the standard to more precisely describe the construction of the wire; - revision to Clause 1, the scope of the standard, to provide more detail of the wire construction; - revision to 3.2.2, general winding wire requirements of the glass fibre covering.
