IEC 60404-17:2021
Magnetic materials - Part 17: Methods of measurement of the magnetostriction characteristics of grain-oriented electrical steel strip and sheet by means of a single sheet tester and an optical sensor
Matériaux magnétiques - Partie 17: Méthodes de mesure des caractéristiques de magnétostriction des bandes et tôles magnétiques en acier à grains orientés au moyen d’un essai sur tôle unique et d’un capteur optique
| Označení normy: | IEC 60404-17:2021 |
| Vydáno: | 2021-11-04 |
| Jazyk: | Anglicky/Francouzsky |
IEC 60404-17:2021
IEC 60404-17:2021 is applicable to grain-oriented electrical steel strip and sheet specified in IEC 60404-8-7 for the measurement of magnetostriction characteristics under an applied AC magnetic field at 50 Hz or 60 Hz. This document defines the general principles and technical details of the measurement of magnetostriction characteristics of grain-oriented electrical steel strip and sheet by means of a single sheet tester and an optical sensor. This document is applicable to the measurement of: the butterfly loop; the peak-to-peak value λp-p; the zero-to-peak value λ0-p. The magnetostriction characteristics are determined for a sinusoidal induced secondary voltage, for a specified peak value of the magnetic polarization and at a specified magnetizing frequency.
