sklademVydáno: 2022-03-04
IEC 61169-17:2022
Radio-frequency connectors - Part 17: Sectional specification for RF coaxial connectors with inner diameter of outer conductor 6,5 mm (0,256 in) with screw coupling - Characteristic impedance 50 ohms (Type TNC)
Connecteurs pour fréquences radioélectriques - Partie 17: Spécification intermédiaire relative aux connecteurs RF coaxiaux à couplage à vis avec conducteur extérieur présentant un diamètre intérieur de 6,5 mm (0,256 in) - Impédance caractéristique de 50 ohms (type TNC)
Formát
Dostupnost
Cena a měna
Anglicky/Francouzsky Tisk
skladem
4290 Kč
Anglicky/Francouzsky PDF
K okamžitému stažení
4290 Kč
| Označení normy: | IEC 61169-17:2022 |
| Vydáno: | 2022-03-04 |
| Jazyk: | Anglicky/Francouzsky |
Popis
IEC 61169-17:2022
IEC 61169-17:2022, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for series TNC RF coaxial connectors with threaded coupling with a characteristic impedance of 50 Ω. This document prescribes mating face dimensions for high performance connectors - grade 2, dimensional details of standard test connectors - grade 0, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series TNC RF connectors. This document indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.
