sklademVydáno: 2014-10-23
IEC 61169-50:2014
Radio-frequency connectors - Part 50: Sectional specification for RF coaxial connectors with inner diameter of outer conductors 4,11 mm with quick lock system - Characteristics impedance 50 Ohm (type QMA)
Connecteurs pour fréquences radioélectriques - Partie 50: Spécification intermédiaire relative aux connecteurs coaxiaux pour fréquences radioélectriques avec diamètre intérieur des conducteurs extérieurs de 4,11 mm à système de verrouillage rapide - Impédance caractéristique 50 Ohms (type QMA) système de verrouillage rapide. Impédance caractéristique 50 Ohms
Formát
Dostupnost
Cena a měna
Anglicky/Francouzsky Tisk
skladem
4290 Kč
Anglicky/Francouzsky PDF
K okamžitému stažení
4290 Kč
| Označení normy: | IEC 61169-50:2014 |
| Vydáno: | 2014-10-23 |
| Jazyk: | Anglicky/Francouzsky |
Popis
IEC 61169-50:2014
IEC 61169-50:2014, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for type QMA R.F. coaxial connectors with quick lock. The connectors are normally used with 50 Ohms corrugated cable and flexible cables for middle power applications in an operating range up to 6 GHz. It describes the interface dimensions for general purpose connectors with gauging information and the mandatory tests selected from IEC 61169-1, applicable to all detail specifications relative to type QMA connectors. This specification indicates the recommended performance characteristics to be considered when writing a DS and covers all tests schedules and inspection requirements.
