sklademVydáno: 2021-02-23
IEC 61169-66:2021
Radio-frequency connectors - Part 66: Sectional specification for RF coaxial connectors with 5 mm inner diameter of outer conductor, with quick-lock- or screw-coupling, characteristic impedance 50 Ω (series 2,2-5)
Connecteurs pour fréquences radioélectriques - Partie 66: Spécification intermédiaire relative aux connecteurs coaxiaux pour fréquences radioélectriques avec diamètre intérieur du conducteur extérieur de 5 mm à couplage à verrouillage rapide ou à vis, impédance caractéristique de 50 Ω (série 2,2-5)
Formát
Dostupnost
Cena a měna
Anglicky/Francouzsky Tisk
skladem
6721 Kč
Anglicky/Francouzsky PDF
K okamžitému stažení
6721 Kč
| Označení normy: | IEC 61169-66:2021 |
| Vydáno: | 2021-02-23 |
| Jazyk: | Anglicky/Francouzsky |
Popis
IEC 61169-66:2021
IEC 61169-66:2021 provides information and rules for the preparation of detail specifications (DS) for series 2,2-5 RF coaxial connectors with quick-lock- or screw coupling, characteristic impedance 50 Ω, for operating frequencies up to 6 GHz. Typical use is in wireless telecommunication systems. It describes mating face dimensions for general purpose connectors - grade 2, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series 2,2-5 RF connectors. This specification indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.
