ISO/TS 10303-1678:2006

ISO/TS 10303-1678:2006 specifies the application module for Functional decomposition with nodal representation to packaged mapping. ISO/TS 10303-1678:2006 deals with the representation of the information needed to describe the assignment of a set of nodes in a hierarchical network definition to a single node in a non-hierarchical network definition for an assembly design. The set of nodes in the hierarchical network satisfy a transitive closure property, i.e. any node in the set shall be reachable from any other node in the set by traversing only network definitions that contain a node in the set. The graph representation of the hierarchical network definition shall be directed. The following is within the scope of ISO/TS 10303-1678:2006: mapping between a set of nodes in the functional hierarchical network and a single node in the physical network.
