sklademVydáno: 2018-02-28
PD IEC/PAS 61076-3-126:2018
Connectors for electrical and electronic equipment. Product requirements Rectangular connectors - Detail specification for 5 pole power connector for industrial environments with push-pull locking
Formát
Dostupnost
Cena a měna
Anglicky Zabezpečené PDF
K okamžitému stažení
8990 Kč
Anglicky Tisk
Skladem
8990 Kč
| Označení normy: | PD IEC/PAS 61076-3-126:2018 |
| Počet stran: | 46 |
| Vydáno: | 2018-02-28 |
| ISBN: | 978 0 580 51535 4 |
| Status: | Standard |
Popis
PD IEC/PAS 61076-3-126:2018
This standard PD IEC/PAS 61076-3-126:2018 Connectors for electrical and electronic equipment. Product requirements is classified in these ICS categories:
- 31.220.10 Plug-and-socket devices. Connectors
This document covers rectangular IP65/IP67 connectors with 5 poles for electric power supply up to 16 A. These connectors consist of fixed and free connectors, either rewirable or non-rewirable (for both portions). It uses the general function principles of the push-pull connector housing system described in IEC 61076-3-117 with IP65/IP67 degree of protection according to IEC 60529 for harsh applications.
Male connectors have 5 square 1 mm electric contacts, with 16 A rated current. Connectors according this document are without breaking capacity COC according to IEC 61984, therefore they are not intended to be engaged or disengaged in normal use when live or under load, if not otherwise specified by the manufacturer.
